Terminal Barrier Block-2Pin

Material

• Pitch: 9.6 mm
• Screws:  M4 Steel Ni plated
• Clamp: Brass,Ni plated
• Pin header: Brass,Tin plated

Electrical

• Rated voltage: 300V
• Rated current: 20A
• Insulation resistance: 5000M/DC1000V
• Withstanding voltage: AC 2000V/1 Min
• Wire range: 22-12AWG 4mm²

Mechanical

• Temp.Range: -40~+105
• MAX Soldering: +250,for 5 Sec.
